Building a campervan can be a huge project, but the VW T7/ New Ford transit custom furniture kit is here to make it simple. Every piece is pre-scribed to match your van's exact contours, which means no more tedious measuring or cutting. The kit fits perfectly, saving you countless hours and minimizing mistakes.
Assembly is incredibly easy with the innovative integrated floor system. You simply click the pieces into the floor base, wire your appliances, and then slide the complete unit into place.
The standard design offers maximum storage accommodating any 112 bed. This kit includes full-length overhead lockers for all your storage needs and the option of solid Bamboo worktop and table that adds a touch of class to your new kitchen.
Spec.
- High pressure laminated birch
- Real oak tambour door
- Real oak or flush handles
- Integrated floor system for simple installation
- Soft close drawer
- Soft close door hinges
- Overhead LED top locker
- Full size window surround splashback
- Full LED shelving system throughout
- Kickboards for Rock ‘N’ Roll Bed
- Table with folding leg - leg colour matched to your handles
- New rail design: laminated birch rail to compliment your kit
- Table storage system
- LED cubby hole
- Worktop storage flap
- Grill/sink cut outs with flush design
- Coasters
- Barn door table rail
- Easy to follow picture instructions
SWB
Overall length: 2165mm | Height 1300mm
Includes 2 x doors in top locker
LWB
Overall length 2565mm | Height 1340mm
Includes 3 x doors in top locker
Work top
Height: 775mm
Fridge Aperture
Width: 390mm | Height 536mm
Aperture will accommodate most popular campervan 12v fridges, however the fridge door can’t protrude past the fridge width, we recommend our Revace 50L fridge
Rock & Roll bed
Suitable for beds 112cm or smaller
Van floor
Must have an overall thickness no greater than approx 20mm from the ribs
Ply-Lining
Must have Two-piece ply-ling on O/S with full height rear quarter
Worktop appliances
Gas twin burner and sink – Dometic 9722 RHS (undermount fit)
Sink – Can LA1400 320 x 260 (undermount fit) Includes LP1800 waste
Single induction – Sterling power IH2L 1000W
Twin induction – Sterling power IHFB 2800W
Please note:
Kickboards may need scribing NS dependant on bed position
Trimming may be required with glidemotion bed system
